ASTRA-LR
TRIPOD LASER TARGET DESIGNATOR LONG RANGE
FOR JFO AND JTAC
FOR JFO AND JTAC
Main modules
- Designation / Range finder unit
- Pan & Tilt head
- Battery
- Remote control unit
Validated integrations with
- Handheld optronics systems
- Fire-Control Systems
- Seespot
- Compatibility with other equipments
Accessories
- Ask for CILAS wide portfolio
MAIN USERS
- Joint Terminal Attack Controllers (JTACs)
- Special Forces (SF)
- Artillery Observers (AO)
| TECHNICAL SPECIFICATIONS | |
|---|---|
|
WEIGHT |
≤ 2.9 kg |
| OPERATING TEMPERATURE | -21C° to +50°C |
| OUTPUT ENERGY | > 70 typical 80 mJ |
| BEAM DIVERGENCE | ≤ 350 Typical ≤260 μrad |
| TELEMETRY RANGE | From 300m up to 10km |
| COMPLIANCE | STANAG 3733 / MIL STD 810 / AECTP 400 / AECTP 500 |
| COMPATIBILITY | NATO / NON-NATO ammunitions |
