DHY 208
NEW GENERATION LASER TARGET DESIGNATOR
THE ULTRA-COMPACT LASER TARGET MARKER
- Compliant with nato and non-nato laser-guided weapons
- Ultra lightweight system
- Near IR pointer
- Digital magnetic compass in option
- Athermal diode pumped laser
- No warm up needed
- Compliant with stanag 3733
ULTRA LIGHTWEIGHT AND PRECISE
Main modules
- Designation/rangefinding unit
- Tripod
- Fire switch
- Digital Magnetic Compass (DMC) in option
- GPS in option
Validated integrations with
- Hand-Held Thermal Imagers (HHTI)
- Target locators
- Digital Aided Close Air Support (DACAS)
- Fire-Control Systems (FCS)
Accessories
- Ask for CILAS wide portfolio
EQUIPMENT IN SERVICE IN SEVERAL COUNTRIES
| GENERAL PARAMETERS | |
|---|---|
| WEIGHT WITH BATTERY & RCU | < 2 kg |
| OPERATING TEMPERATURE | -10°C to +50°C |
| DESIGNATION PARAMETERS | |
|---|---|
| OUTPUT ENERGY | > 30 mJ |
| BEAM DIVERGENCE | < 0.4 mrad |
| RANGE | 6 km on buildings 3 km on OTAN targets |
| LASER RANGE FINDER PARAMETERS | |
|---|---|
| DISTANCE | 20 km |
| EXTINCTION RATE | > 40 dB |
| NIR PARAMETERS | |
|---|---|
| NIR POWER | > 0.75W |
| NIR WAVELENGHT | 830 nm |
